  • Multi Mill

    • Multi Mill

    Multi Mill a self – contained portable unit useful for high-speed granulation, pulversing, mixing, shredding and chopping of wide range of wet and dry materials with special attachments called beater which have Knife/Impact blades and Scrapper blades (Standard) to get the required size reduction.
    Desired output of product depends on wide range of model selection which varies through direct driven, belt driven, perforated screen size & motor HP. Multi Mill is widely used in pharmaceutical industries, food industries, R&D purpose, pharmacy colleges for education purposes, etc.

    Category

    Overview

    Multi Mill a self – contained portable unit useful for high-speed granulation, pulversing, mixing, shredding and chopping of wide range of wet and dry materials with special attachments called beater which have Knife/Impact blades and Scrapper blades (Standard) to get the required size reduction.
    Desired output of product depends on wide range of model selection which varies through direct driven, belt driven, perforated screen size & motor HP. Multi Mill is widely used in pharmaceutical industries, food industries, R&D purpose, pharmacy colleges for education purposes, etc.

    Benefits for you:

    • High Speed Operations
    • Minimum Material Handling
    • Dust-free operations
    • Easy to handle
    • Easy maintenance

    Details

    Fluid Bed Dryer
    Fluid Bed Dryer
    Double Cone Blender
    Double Cone Blender
    Tripper
    Tripper
    • Machine Portable on Castor wheels.
    • High output with Process uniformity.
    • Direction of the Blade rotation can be changed using a Reversing switch for Hammer or Knife operation.
    • Multiple combinations of Screens / Speeds / Number of Blades.
    • Direction of blade rotation for every Product type.
    • Higher Screen opening area for Higher Throughput.
    • Easy Dismantling and Cleaning of all Components reducing.
    • Built in variable frequency drive for multiple speed.
    • Noiseless & maintenance free unit.
    • Required less electric power.
    • All contact parts can be easily washed and or/ sterilized.
    • Efficient de-burring & de-dusting and full suction of excess powder.

    It operates on the principle of variable force swing beaters having both knife and impact edges rotating within a selected screen to get the required size reduction.

    Material fed in the hopper, goes down to the processing chamber where it moves to the periphery and passes through the screen radially and tangentially. Finally, the processed material gets collected in the container kept below the processing chamber.

    Output and quality of the final product depends on three main factors: (I) Shape of beaters (knife/impact edges) (II) Speed and (III) Screen.

    BELT DRIVEN
    3 HP/1440 RPM/3 PHASE/415 V/AC
    DOL Starter provided with Reverse/Forward switch
    Motor RPM : 750/1440/2200/2800
    12 Nos of blades with knife & impact edges and 2 no. of scraper blades.
    Output – 50 to 200 Kg/hr

    (Output depending upon the feed product and output required.)
    Foundation is not required as Castor wheel is mounted with the base.
    DIRECT DRIVEN
    3 HP/ 2880 RPM/ 3 Phase/ 415 V/AC
    VFD Provided for regulated RPM
    Motor RPM: 5 to 2850
    12 Nos, of blades with knife & impact edges and 2 no. of scraper blades.
    Output – 50 to 200 Kg/hr

    (Output depending upon the feed product and output required.)
    Foundation is not required as Castor wheel is mounted with the base.
