Paste Kettle Preparation

Overview

Rapid Mixer Granulator is an ideal mixer for pharmaceutical, chemicals, and food products, including aqueous and solvent granulation, wax granulation, dry mixing, and wet granulation.

Rapid Mixer Granulator is designed to achieve excellent mixing and consistent granules at lower operating costs along with higher productivity. Better mixing and closed control of granule size lead to faster tableting speeds with improved quality and least rejections.

Performance Characteristics

Thorough and uniform mixing.
Even size granules
Minimum batch time
Minimum Powder consumption.
Automated charging & discharging.
Total Leak-proof operation.
Thorough cleaning/washing by WIP system.
Better productivity & lesser mixing time.

Details

Unique design incorporating Impeller, Granulator, Online Co-mill, Side Discharge Valve & Dryer.
Meets cGMP requirements.
Parts are easy to dismantle, clean, and re-assemble.
With a Special design Mixer & Chopper blade.
It is provided on the side of the bottom, operated by a SS Spindle connected to a pneumatic cylinder in the closed position, and the gate is flushed with the contour of the bowl.
A cover with a removable silicone rubber seal gives unrestricted access to the chute for easy cleaning.
A safety lock in the form of a limit switch is provided at the discharge port to prevent the valve or the motor to start during the cleaning operation.
The pneumatic cylinder is covered by a stainless steel shroud to meet the cGMP standards.
Binder addition system (Optional)
Inline Co-mill for uniform granules. (Optional)
Flameproof Construction (Optional)
The gasket of Teflon/Silicon.
Optional features of jacketed models, Vacuum/Gravity charging, Mechanical Seals, Binder spraying systems, CIP/WIP systems, Vacuum drying, and SCADA Solutions are available.
ATEX compliant option is available.
Environment friendly.
Heat/Temperature sensitive products can be handled easily.
VFD Controls for Impeller & Chopper.
Intelligent process control and interlock through PLC & colour touch screen HMI with SCADA facility.
Multi options available for impeller blade, Chopper and Co-mill blade & screen.

Technical Specification	LAB MODELS PILOT MODELS
MODEL NO.	AMPL RMG5	AMPL RMG10	AMPL RMG15	AMPL RMG25
Working Capacity in Ltrs	5	10	15	25
Working Capacity in Kgs	4	8	12	20
Main Motor 750/1440 RPM	2/3	2/3	3/5	3/5
Chopper Motor 1440/2880 RPM	0.5/1	0.5/1	0.5/1	0.75/1.5
Gearbox ratio	7 : 1	7 : 1	10 : 1	10 : 1

Technical Specification	PRODUCTION MODELS
MODEL NO.	AMPL RMG50	AMPL RMG75	AMPL RMG100	AMPL RMG250	AMPL RMG400	AMPL RMG600	AMPL RMG800	AMPL RMG1200
Working Capacity in Ltrs	50	75	100	250	400	600	800	1200
Working Capacity in Kgs	20	30	40	100	160	240	320	480
Main Motor 750/1440 RPM	3/5	3/5	5/7	25/30	30/40	50/100	60/75	80/100
Chopper Motor 1440/2880 RPM	1.5/3	1.5/3	1.5/3	3/5	5/7.5	5/7.5	5/7.5	10/15
Gear box ratio	10 : 1	10 : 1	10 : 1	10 : 1	10 : 1	10 : 1	13 : 1	13 : 1
